The innovative new tool
for large-scale second-line
autoantibody screening.
Zenit AMiDot system, an aid to diagnosis
• For Ag typing after IF screening
• For Ag typing after ELISA or CLIA screening
• To complete ELISA and IFA
• To complete CLIA and IFA
Zenit AMiDot at a glance
• 20 quantitative results per patient
• Up to 38 different antibodies or antigens measured
in duplicate per patient
• Integral controls in each well
• Calibration in each well
• Fully automatable using existing IFA instrumentation
• Read time less than 40 seconds per slide
• Printout by patient or by slide
Need toautomate slidemicroarrays?
Look toZenit AMiDot preparedwithZenit UPand read withZenit G-Sight for AMiDot.
Zenit AMiDot employs pre-designed microdot
arrays for a panel of autoimmune diseases, such
as systemic autoimmune disease, autoimmune
vasculitis, idiopathic inflammatory myopathies, ga-
strointestinal autoimmune disease, autoimmune
liver disease.
The immunoassay-based Zenit AMiDot test con-
sists of two components:
Zenit AMiDot Reagent
Kit
containing conjugate, sample diluent and
wash buffer, and a
Zenit AMiDot Slide Pack
con-
taining glass microscope slides with 4 or 8 wells
delineated by a hydrophobic mask. These wells
are coated with an array of autoimmune antigens,
calibrators and controls.
Internal controls built into the Zenit AMiDot array en-
sure that each patient sample has been diluted cor-
rectly and that the test procedure has been followed.
The Zenit AMiDot fluorometer will interpret
the microdot array and produce a report listing
concentration and positive, borderline or ne-
gative status for each antigen if the calibration
and controls meet required specifications.
The Zenit AMiDot range is compatiblewith the Zenit
UP system, and the Zenit G-Sight series as well.
