Automation, productivity, and reliability all in one
UNAMAX is the new A. Menarini Diagnostics urine chemistry analyzer that offers a fully automated approach, maximum productivity and improved analytical performance. UNAMAX can evaluate up to 14 chemical parameters, including ascorbic acid, creatinine, microalbumin, and calcium, as well as 5 physical parameters using the
physical and the conductivity
modules, to deliver high-quality, accurate results. UNAMAX has a throughput of 360 samples/hour and has an easy-to-use 10.4-inch color touchscreen that displays the real strip image for review. The system is equipped with automatic RFID rack recognition for better sample traceability. The constant temperature control ensures the best reaction environment and avoids temperature interference. Pediatric mode available with 0,6ml
minimum sample and pediatric RFID rack recognition.
ADVANCED AUTOMATION AND IMPROVED ACCURACY
- Fully automated
- Contact image sensors (CIS) scanning technology with 5 wavelengths for greater accuracy and efficiency
- Low sample volume needed (at least 2ml with standard
mode or 0,6 ml with
pediatric mode) with liquid level detection sensor
- Precise sample dropping technology
- Automatic enhanced washing for high concentration samples
- Constant temperature control to avoid interference
- Automated quality control analysis and maintenance procedures
ENHANCED PRODUCTIVITY AND TRACEABILITY
- High throughput: 360 samples/hour
- Strip loading capacity: 500 strips
- RFID rack reader
MEASUREMENT FEATURES AND CLINICAL UTILITY
- Up to 14 chemical parameters, including ascorbic acid, creatinine, microalbumin, and calcium
- Albumin-to-creatinine ratio (ACR) to identify early-stage kidney disease and Protein-to-creatinine ratio (PCR)
- 3 different types of strips available (LabUSticks 11F, 12F and 14 F )
- Physical module ensuring accurate specific gravity, turbidity, and color results
- Conductivity module to
provide conductivity and osmolality results.
- Real-time strip reaction color for reviewing EASE OF USE AND LIS INTEGRATION
- User-friendly software and easy-to-use 10.4-inch color touchscreen
- Integration with laboratory or hospital information systems
A winning combination
UNAMAX can be combined with sediMAX conTRUST PRO, the A. Menarini Diagnostics bright-field and phase-contrast urine sediment analyzer, to create a fully automated solution for urine analysis. This advanced combination creates a real urinalysis workstation, improving throughput and increasing analytical accuracy within a routine setting.
- Fully automated BF and PC microscopy
- High throughput: 150 sample/hour
- 20 detected particle classes, including acanthocytes and ghost red blood cells
- Automated urine chemistry analyzer
- High throughput: 360 samples/hour
- Up to14 chemical parameters, including ascorbic acid, creatinine, microalbumin, and calcium
- Albumin-to-creatinine ratio (ACR) to identify early-stage kidney disease and Protein-to-creatinine ratio (PCR)
